Sonel Test Equipment

LXP-10B Light Meter

LXP-10B Light Meter

$870.00
$870.00
Sale Sold out
Shipping calculated at checkout.

Description



Reliable illuminance measurements with the LXP-10B light meter

Model with resolution 0.01 lx allows to accurate lighting measurements in workplaces and emergency lighting in escape routes. It works with LP-10B measuring probe. The device has internal memory of 999 measurements and additional logger for recording data with a selectable sampling rate.

Main features

  • high resolution up to 0.01 lx
  • highly accurate measurements
  • measurements of all types of light sources including:
    • LEDs lamps,
    • incandescent lamps,
    • fluorescent lamps,
    • electrodeless lamps,
    • high and low-pressure lamps
  • no need to using correction factors
  • photodiodes with filters make the spectral sensitivity characteristics well matched to the requirements of C.I.E.

Product functions

  • data-hold for freezing measuring values
  • automatic zeroing
  • peak-hold for freezing the peak signal of light pulse
  • capable of selecting measuring mode in Lux or FC scale
  • MAX and MIN results save
  • relative mode
  • easy to read large backlit display
  • USB connection with PC
  • wireless connection
  • built-in memory: 999 points
  • 16 000 values records data logger
  • auto power off









Technical data





Illumination measurement



The result may be displayed in lx or fc. Displaying fc results with reduced resolution due to the display limitations.



Parameter Description
probe LP-10B
class B
measurement range
lx 0.000...399.9k
fc 0.000...39.99k
resolution
lx 0.01
fc 0.001
spectral uncertainty f1 ’ ±6%
cosine matching error f2 ±3%
accuracy ±(5% m.v. + 5 digits)
number of ranges 5
memory 999 points
logger memory 16 000 points



m.v. - measured value

Technical specification:

  • display: 3¾ digits, LCD with 40-segment bar indicator
  • exceeding of range: “OL” symbol
  • spectral sensitivity: CIE photopic curve (CIE human eye sensitivity curve)
  • power supply: 9 V battery or 8.4 V rechargeable battery
  • photodetector: one silicon photodiode and spectral curve filter
  • communication interface: USB and wireless
  • operating temperature: 0...50°C | 32...122°F
  • operating relative humidity: 0...80%
  • storage temperature: -20...+70°C | -4...+158°F



Weight and dimensions

Parameter Value
Net weight (kg) 0.3
Package weight (kg) 1.9
Package width (cm) 10.6
Package height (cm) 28.5
Package length (cm) 39.8
