LXP-10A Light Meter

Regular price $1,080.00

Shipping calculated at checkout.



LXP 10A additional files link

The new LXP digital light meter family allows for a very precise measurement of illuminance. Thanks to very high resolution (resolution 0.001 lx ) allows for escape route emergency light measurement. All of three light meter have built-in memory for measurement result storing, and additional function making work much easier.






--

The most important features:


    • Measurement resolution:  0.001 lx (0.001 fc).

    • High accuracy and fast response.

    • Data-hold function for holding measuring values.

    • Automatic zeroing.

    • No need for correction factors calculating  for different light sources thanks to a very good fit spectral sensitivity guaranteeing the correct measurement of intensity of the illumination regardless of the nature of radiation.

    • Peak-hold function for tracing the peak signal of light pulse with duration longer than 0.1 s and less than 1 s.

    • Capable of selecting measuring mode in Lux or FC scale alternatively.

    • Auto power off (5,10 or 15minutes) or disable AUTO power off.

    • Maximum and minimum measurements.

    • Relative reading.

    • Easy to read large backlit display.

    • USB output connect with PC.

    • Data transmission via radio connection using an optional adapter OR-1.

    • Six measurement ranges.

    • Built-in memory -  999, with can be checked in the meter or PC.

    • 16000 values records data logger (traceable only in PC).


Illuminance measurement probe LP-10A:



































Display
Range
[lx]
Resolution
[lx]
Spectral
uncertainty
Accuracy
0 to 3.999 0.001 f1 < 2% ±(2 % + 5 digits)
4.00 to 39.99 0.01
40.0 to 399.9 0.1
400 to 3,999 1
4.00 k to 39.99 k 0.01 k
40.0 k to 399.9 k 0,1 k

































Display
Range
[fc]
Resolution
[fc]
Spectral
uncertainty
Accuracy
0 to 3.999 0.001 f1 < 2% ±(2 % + 5 digits)
4.00 to 39.99 0.01
40.0 to 399.9 0.1
400 to 3999 1
4.00 k to 39.99 k 0.01 k

- display result in lx or fc (display result in fc with reduced resolution due to limitations of display)
- meter class A

Rated operational conditions:




        • operating temperature: 32F to 122F / 0 to 50°C,

        • operating humidity: 0% to 80% RH,

        • storage temperature: -4F to 158F / -20 to 70°C,

        • storage humidity: 0% to 70% RH.




Other technical data:

    • display: 3¾ digit LCD with high speed 40 segment bargraph,

    • over range indication: „0L” displayed,

    • spectral response: CIE photopic (CIE human eye response curve),

    • cosine response (f2’): ±3%,

    • sampling rate: 1,3 times/sec,

    • power supply: battery 9V or rechargeable battery 8,4 V,

    • photo detector: one silicon photo diode and spectral response filter,

    • memory: 999 results

    • photo detector lead length: approx. 59" / 150cm,

    • photo detector dimensions: 4.52" x 2.36" x 0.78" / 115 × 60 × 20mm,

    • meter dimensions: 6.69" x 3.15" x 1.57" / 170 × 80 × 40mm,

    • weight: 0.86 lbs / 390g,

    • data transmission: USB cable or Bluetooth®
